CX1600S BL Hot Air Welding Machine

The hot air guns CX1600S BL are suitable for welding various thermoplastic materials such as PE, PP, PVC, PVDF, TPO and are widely used in various industrial applications such as floor welding, membrane waterproofing welding, sheet welding, pipe welding.

 button icon

Product Details

 button icon

Contact Now

Product Details

Product Video

Application

The hot air guns CX1600S BL are suitable for welding various thermoplastic materials such as PE, PP, PVC, PVDF, TPO and are widely used in various industrial applications such as floor welding, membrane waterproofing welding, sheet welding, pipe welding.

Parameter Table

Voltage 220V
Frequency 50/60Hz
Power 1600W
Temp Adjusted 20-620℃ Adjustable Continuously
Air Volume Max 180L/min
Air Pressure 2600Pa
Noise ≤65 Db
Application PE/PP/PVC/ABS/PVDF

Product Features

① Welding Nozzles
Suitable for various welding nozzles to meet different needs.
② Heating Element
Import heating elements can make it work for a long time under high temperature.
③ Temperature Control System
Protect heating elements burned to stop heating when temperature is higher than secure working temperature.
④ Brushless Motor
The use of brushless motor makes it more efficient and consumes less energy, long service life.
⑤Delay System
The hot air gun automatically turns off the fan after a 5-minute delay.
⑥ Lighting
Equipped with LED lights and independent switch control.
⑦ Handle
The handle is thinner and lighter, making it easier to operate.

Parts List

  • CX1600S BL Hot Air Welding Machine

    1600W/220V heating element

  • CX1600S BL Hot Air Welding Machine

    1600W/110V heating element

  • CX1600S BL Hot Air Welding Machine

    20mm slot nozzle

  • CX1600S BL Hot Air Welding Machine

    40mm slot nozzle

  • CX1600S BL Hot Air Welding Machine

    20 mm 120°angled nozzle

  • CX1600S BL Hot Air Welding Machine

    20 mm 90°angled nozzle

  • CX1600S BL Hot Air Welding Machine

    5mm tubular nozzle

  • CX1600S BL Hot Air Welding Machine

    5mm round speed nozzle

  • CX1600S BL Hot Air Welding Machine

    5*7 triangle speed nozzle

  • CX1600S BL Hot Air Welding Machine

    tacking nozzle

  • CX1600S BL Hot Air Welding Machine

    20mm silica roller

  • CX1600S BL Hot Air Welding Machine

    40mm silica roller

  • CX1600S BL Hot Air Welding Machine

    20mm teflon roller

  • CX1600S BL Hot Air Welding Machine

    Brass roller

  • CX1600S BL Hot Air Welding Machine

    Green plastic carry box

Weldable Materials

  • CX1600S BL Hot Air Welding Machine

    PE (HDPE, LDPE)

  • CX1600S BL Hot Air Welding Machine

    PP

  • CX1600S BL Hot Air Welding Machine

    PVC
